Thermal protector CS2A - Temperature 170°C - Cables 70/70 mm - Rated current 8A
search
  • Thermal protector CS2A - Temperature 170°C - Cables 70/70 mm - Rated current 8A

Thermal protector CS2A - Temperature 170°C - Cables 70/70 mm - Rated current 8A

€2.94

Product code: PTCS2A-170-7070

Quantity Price per piece
1-9 2,94 €
10-19 2,21 €
20-29 1,76 €
30-39 1,47 €
40+ 1,18 €

Volume discounts

Quantity Unit price You Save
10 €2.21 Up to €7.30
20 €1.76 Up to €23.60
30 €1.47 Up to €44.10
40 €1.18 Up to €70.40
Quantity
  Shipping policies

Courier: UPS Costs: 20,90€ in EU, 50€ rest of world Delivery time: 5/7 days in EU, 5/15 rest of w

  Since 1999

We work with an extensive worldwide network of manufacturing companies.

  Customer service

Always by your side for pre and post-sales support.

PTCS2A-170-7070

Data sheet

Type of Product
Thermal protector
Model code
CS2A
Opening temperature
170°C
Reset temperature
114°±5°C
Tolerance
±5°C
Contact position
Normally closed
Lead lenght in mm
70/70
Dimensions in mm
15 x 6 x 3
Rated current
8A / 250V
Number of cycles at 8A
10.000
Maximum current
12A / 125V
Suitable for vacuum impregnation
Yes
Manufacturer code
CS2-A-170
Approval
CQC
TUV
UL
VDE
